Prototype-to-Production
Full-Service Precision CNC Machining Partner for Difficult Alloys
AXALLOY Precision is a Shenzhen-based CNC machining partner specializing in complex, high-value components made from difficult-to-machine alloys. We support international engineering, procurement and quality teams from prototype development through low-volume and repeat production.
Our Prototype-to-Production approach delivers engineering prototypes, design validation, controlled low-volume manufacturing and repeatable production — all while maintaining the highest levels of quality, traceability and process control.
Precision Machining for Difficult Alloys
Our Prototype-to-Production methodology ensures seamless transition from design validation to repeatable manufacturing, with rigorous quality control at every stage.
Multi-axis Milling
3-axis, 4-axis and 5-axis machining for complex contours, pockets, thin walls and precision interfaces.
Turning and Mill-Turn
Precision turned and combined mill-turn components requiring fewer setups and stronger feature relationships.
Special Processes
EDM, precision grinding, heat treatment, passivation, coating, deburring, marking, cleaning and assembly support.
Engineering Support
Drawing review, DFM feedback, tolerance review, fixture planning and manufacturing-process development.
Inspection and Documentation
Material traceability, first article inspection, dimensional reports, certificates and project-specific quality records.
Material Focus
Nickel-based superalloys, titanium alloys, precipitation-hardening stainless steels, duplex and super duplex stainless steels, cobalt-based alloys and selected specialty metals.
General Machining Capabilities
| Parameter | Standard Capability |
|---|---|
| Supported Production Volume | 1–10,000+ parts |
| Prototype Quantity | 1–20 parts |
| Low-Volume Production | 20–500 parts |
| Batch Production | 500–10,000+ parts |
| Standard Dimensional Tolerance | ±0.010 mm |
| Precision Dimensional Tolerance | ±0.005 mm |
| Standard Angular Tolerance | ±0.5° |
| Precision Angular Tolerance | ±0.1° |
| Position Tolerance | Down to 0.010 mm |
| Flatness | Down to 0.005 mm |
| Concentricity | Down to 0.008 mm |
| Standard Surface Finish | Ra 1.6 μm |
| Precision Machined Finish | Ra 0.8 μm |
| Ground Surface Finish | Down to Ra 0.2 μm |
| EDM Surface Finish | Down to Ra 0.8 μm |
| Minimum Wall Thickness | 0.5 mm |
| Minimum Machined Hole Diameter | Ø0.5 mm |
| Minimum Thread Size | M1.0 |
| Maximum Part Weight | 1,000 kg |
| Standard Lead Time | 10–20 business days |
| Prototype Lead Time | 5–10 business days |
| Expedited Service | Available |
| Minimum Order Quantity | 1 part |
CNC Milling
- 3-axis, 4-axis and 5-axis CNC milling
- Max 3-Axis Part Size: 1,000 × 600 × 600 mm
- Max 4-Axis Part Size: Ø500 × 800 mm
- Max 5-Axis Part Size: Ø500 × 400 mm
- Max Table Load: 800 kg
- Positioning Accuracy: ±0.005 mm
- Repeatability: ±0.003 mm
- Min Internal Corner Radius: R0.3 mm
- Operations: Facing, contouring, pocketing, drilling, tapping, boring, thread milling
- Suitable Parts: Housings, brackets, manifolds, impellers, blades, plates, complex structural components
CNC Turning & Mill-Turn
- 2-axis CNC turning and live-tool turning
- Max Turning Diameter: Ø500 mm
- Max Turning Length: 1,000 mm
- Max Machining Diameter (Mill-Turn): Ø400 mm
- Max Machining Length (Mill-Turn): 800 mm
- Turning Tolerance: Down to ±0.005 mm
- Concentricity: Down to 0.008 mm
- Roundness: Down to 0.005 mm
- Operations: Turning, milling, drilling, tapping, boring, grooving, off-center machining
- Suitable Parts: Shafts, sleeves, bushings, pins, nozzles, fittings, valve parts, threaded components
Swiss CNC Turning, Wire EDM & Sinker EDM
- Swiss CNC Turning: Ø32 mm bar, up to 7 axes, down to Ø0.5 mm
- Wire EDM: 600 × 400 × 300 mm, ±0.005 mm accuracy, Ra 0.8 μm
- Sinker EDM: 500 × 350 × 300 mm, Ra 0.4 μm, R0.05 mm internal corners
Precision Grinding
- Surface, cylindrical and centerless grinding
- Tolerance: Down to ±0.002 mm
- Surface Finish: Down to Ra 0.2 μm
Inspection & Quality Documentation
- CMM Accuracy: Up to 1.8 + L/300 μm
- Optical Measurement: ±0.002 mm
- Full Material Traceability, First Article Inspection, Dimensional Reports
- Certificates of Conformance, Heat Treatment & Coating Certificates
- Temperature-controlled inspection room
- Custom inspection plans available
Supported File Formats
3D CAD
STEP, STP, IGES, IGS, X_T, X_B, SLDPRT, SAT
2D Drawings
PDF, DWG, DXF
Compressed
ZIP, RAR
Maximum Upload Size
500 MB per RFQ
Best-Fit Customers & Projects
AXALLOY is best suited to customers that value manufacturability, process control, documentation and dependable communication — not simply the lowest unit price.
Industries
Aerospace, medical devices, semiconductor equipment, energy, oil and gas, marine, robotics, automation and precision industrial equipment.
Markets
North America, Europe, the United Kingdom, Australia, New Zealand and advanced manufacturing markets across Asia.
Company Types
OEMs, Tier 1 and Tier 2 suppliers, engineering firms, contract manufacturers and product-development companies.
Strong Project Inputs
Complete 2D drawings and 3D models, defined materials, identified critical features, expected quantities, required documentation and a realistic target date.
Not an ideal fit for commodity parts purchased only on lowest price, incomplete technical requirements, unverified certification demands or unauthorized component reproduction.
Why Choose AXALLOY for Prototype-to-Production?
Prototypes in Business Days
Rapid turnaround for engineering validation and design iteration.
Controlled Production Volumes
From low-volume pilot runs to repeat batch production.
Compromises on Difficult Alloys
Specialized expertise in nickel, titanium and superalloy machining.
Traceability & Documentation
Export-ready quality records with full material certification.
Engineering Support
From drawing review to first-article inspection, our team guides every project.
mm Precision Grinding Tolerance
The tightest tolerances for critical mating surfaces and interfaces.
Start Your Prototype-to-Production Program
Contact our team today to discuss your next Prototype-to-Production program. Send us your drawings and specifications for a detailed engineering review and competitive quote.
